Trailer SumoSprings (Spring-Under Axle Configuration) - Includes line relocation bracket - 1,400 lb. Capacity

Have a Question ? Talk to a specialist- Live chat or call 877-507-0944
Trailer SumoSprings (Spring-Under Axle Configuration) - Includes line relocation bracket - 1400 (lb) Capacity at 50% Compression
The TSS-106-40 is designed for trailer frames with a GAWR of 3,000-5,000 lbs with the spring sitting underneath the axle tube. The Blue SumoSprings shouldnt be compressed past 70% of their original height in order to keep full memory rebound.
NOTE:
This product is designed to work on most trailers with the springs mounted below the axle. Because of the varying build designs from different trailer manufacturers, there are occasionally some models that this product will not fit. For installation of Trailer SumoSprings the gap between the top of the leaf spring and bottom of the frame must be between 6 and 8.65.
Note: SuperSprings International products are specifically designed for vehicles equipped with factory suspension. We cannot guarantee their compatibility with aftermarket products or parts. For questions about fitment on your specific vehicle, please contact us.
NOTE: TSS-CTP also needed for trailers with springs not directly under frame rail. One kit per axle.
WARNING: Cancer and Reproductive Harm. For more information, go to www.P65Warnings.ca.gov.
Product Details
- Sold as a pair (left and right)
- Maintenance-free
- Reduces and absorbs vibration
- 1400 (lb) Capacity at 50% Compression
- Reduces overall cost of ownership
- Improves overall driver control and ride comfort
- Compress up to 80% of original height with full memory rebound
- Increases safety
- progressive spring rate with superior damping properties
- Made from patented micro-cellular urethane
- Will not leak or rupture
- Never load any vehicle beyond the manufacturers GVWR
Specifications
Brand | SumoSprings |
---|---|
Dimensions | 10.75 × 7.25 × 4.5 in |
Warranty | Limited Lifetime Warranty |
